BTS5215LAUMA1
Datasheet
1MB
Specifications
| Digi-Key Part Number | BTS5215LAUMA1TR-ND – Tape & Reel (TR) |
| BTS5215LAUMA1CT-ND – Cut Tape (CT) | |
| BTS5215LAUMA1DKR-ND – Digi-Reel® | |
| Manufacturer | Infineon Technologies |
| Manufacturer Product Number | BTS5215LAUMA1 |
| Description | IC PWR SWITCH N-CHAN 1:1 DSO-12 |
| Detailed Description | Power Switch/Driver 1:1 N-Channel 3.7A PG-DSO-12-9 |
| Category | Integrated Circuits (ICs) |
| PMIC – Power Distribution Switches, Load Drivers | |
| Mfr | Infineon Technologies |
| Series | – |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| Switch Type | General Purpose |
| Number of Outputs | 2 |
| Ratio – Input:Output | 1:01 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage – Load | 5.5V ~ 40V |
| Voltage – Supply (Vcc/Vdd) | Not Required |
| Current – Output (Max) | 3.7A |
| Rds On (Typ) | 70mOhm |
| Input Type | Non-Inverting |
| Features | – |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-DSO-12-9 |
| Package / Case | 12-BSOP (0.295″, 7.50mm Width) Exposed Pad |
| Base Product Number | BTS5215 |
