LQP03TG2N7B02D

Datasheet

1MB

Specifications



Digi-Key Part Number 490-14702-2-ND – Tape & Reel (TR)
490-14702-1-ND – Cut Tape (CT)
490-14702-6-ND – Digi-Reel®
Manufacturer Murata Electronics
Manufacturer Product Number LQP03TG2N7B02D
Description FIXED IND 2.7NH 450MA 250MOHM SM
Manufacturer Standard Lead Time 21 Weeks
Detailed Description 2.7 nH Unshielded Thick Film Inductor 450 mA 250mOhm Max 0201 (0603 Metric)
Category Inductors, Coils, Chokes
Fixed Inductors
Mfr Murata Electronics
Series LQP03
Package Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
Product Status Active
Type Thick Film
Material – Core Non-Magnetic
Inductance 2.7 nH
Tolerance ±0.1nH
Current Rating (Amps) 450 mA
Current – Saturation (Isat)
Shielding Unshielded
DC Resistance (DCR) 250mOhm Max
Q @ Freq 13 @ 500MHz
Frequency – Self Resonant 6GHz
Ratings
Operating Temperature -55°C ~ 125°C
Inductance Frequency – Test 500 MHz
Mounting Type Surface Mount
Package / Case 0201 (0603 Metric)
Supplier Device Package 0201 (0603 Metric)
Size / Dimension 0.024″ L x 0.012″ W (0.60mm x 0.30mm)
Height – Seated (Max) 0.013″ (0.33mm)
Base Product Number LQP03TG
